| SPECIFICATION |
| OVERALL LENGTH(mm) |
9,198 |
| OVERALL WIDTH (mm) |
2,490 |
| OVERALL HEIGHT (mm) |
2,000 |
| TREAD (mm) |
FRONT |
2,050 |
| REAR |
1,853 |
| OVERHANG (mm) |
FRONT |
1,783 |
| REAR |
2,715 |
| WHEEL BASE (mm) |
4,700 |
| ENGINE |
MODEL |
DL08 |
| HORSE POWER(ps) |
270 |
| TORQUE(kg.m) |
100 |
| DISPLACEMENT(cc) |
7,640 |
| MIN TURNING RADIUS (m) |
10.4 |
| FUEL TANK (L) |
200 |
| SUSPENSION |
FRONT/REAR |
AIR SPRING |
| TIRE |
FRONT/REAR |
11R 22.5-16PR |
|
|
|
BH120F
