BH120F
BH117L
BH117K
FX116K
BV115N
BS120CN
BS120SN
BC212MA
BS106L
BS090L
BF106L
SPECIFICATION
OVERALL LENGTH(mm) 11,449
OVERALL WIDTH (mm) 2,490
OVERALL HEIGHT (mm) 1,867
TREAD (mm) FRONT 2,050
REAR 1,853
OVERHANG (mm) FRONT 2,170
REAR 3,063
WHEEL BASE (mm) 6,100
ENGINE MODEL DE12TIS DE08TIS
HORSE POWER(ps) 310 240
TORQUE(kg.m) 125 90
DISPLACEMENT(cc) 11,051 8,071
MIN TURNING RADIUS (m) 11.7
FUEL TANK (L) 320(200)
SUSPENSION FRONT/REAR LEAF SPRING
TIRE FRONT/REAR 11R 22.5-16PR
